WSN Series 20W LED Wall Pack 110-277VAC 2000lm cETLus Listed for Wet Locations

100lm/W High Efficacy LED Wall Pack, -40°C to +50°C Operation, Replaces 50-100W MH/HID Fixtures

A-WSN-20W-345K-BK/A-WSN-20W-345KP-BK/A-WSN-20W-345KP-WH/A-WSN-20W-345K-WH

cETLus Listed LED Wall Pack with Surge Protection, RoHS Compliant for Commercial Outdoor Illumination

FEATURES

WSN Series 20W LED Wall Pack is a high-performance outdoor luminaire engineered for commercial building doorway and pathway illumination, delivering exceptional energy efficiency and long-lasting performance while replacing traditional 50W-100W MH/HID fixtures.

Boasting a 100lm/W efficacy rating and 2000lm luminous flux, this LED wall pack operates on a wide 110-277Vac 60Hz input voltage, with a high power factor (>0.9 at full load), CRI>80, and total harmonic distortion <20% at full load for stable electrical performance.

It features integral 2.5kV surge suppression protection (10kV optional, tested per IEEE/ANSI C62.41.2) and is qualified to operate in extreme ambient temperatures from -40°C to +50°C, making it ideal for harsh outdoor conditions. Constructed with precision-molded proprietary acrylic lenses for application-specific photometric distributions, the wall pack is equipped with 24x2 LEDs (120mA) available in 3000K/4000K/5000K color temperatures, with a lumen maintenance factor of 78% at 100,000 operating hours (tested per IESNA LM-80-08, projected per IESNA TM-21-11).

Certified cETLus Listed and suitable for wet locations, it meets ANSI C136.31-2001 (3G vibration standards), FCC Part 15 emissions standards, and withstands 3,000 hours of salt fog conditions (ASTM Standard B117). RoHS compliant and available in black/white housing with an optional photocell, this easy-to-install LED wall pack offers reliable, low-maintenance illumination for nearly all commercial and industrial facilities.
