Led Exit Sign Emergency Light EX06 Series
EX06 · Exit Signs

Led Exit Sign Emergency Light EX06 Series

IP65 outdoor LED combo exit sign with dual emergency heads — 120/277V, 5000K, 90

SKU: A-EX06-NV-5K-WH|
In Stock
UL Listed
5-Year Warranty
$42.00

Volume pricing available

Pro & Volume Pricing Available

Contractors, distributors, and trade partners — create a Pro account for exclusive pricing, or request a quote for multi-unit projects.

📦 Sold in cases of 6. Full cartons ship more efficiently.
In Stock — Ships within 1-2 business days from CA
Free shipping on orders over $499
Need help? (626) 364-9198 or sales@auvolar.com

IP65 outdoor LED combo exit sign with dual emergency heads — 120/277V, 5000K, 90-minute backup.

The EX06 series combines exit signage with dual adjustable emergency heads in a single IP65 wet-location-rated unit. ABS housing with polycarbonate cover, 4.8W/2.4W output/input, and universal J-box mounting pattern.

IP65 Combo Unit

Integrates exit sign and two adjustable emergency light heads in a single IP65-rated enclosure. Reduces installation points and maintains wet location protection for both functions.

Dual Emergency Heads

Two adjustable LED emergency heads provide directional egress path illumination at 5000K color temperature. Heads can be aimed independently to cover different areas along the escape route.

Universal J-Box Mount

Standard junction box mounting pattern enables quick installation on existing electrical boxes. Compatible with wall and ceiling mounting for versatile placement options.

Input

120/277VAC
Dual voltage

CCT

5000K
Emergency head color

Backup

90 min
Battery backup

LightSpec AI

Free Lighting Layout
IES-based photometric simulation
120/277VAC
Input
5000K
CCT
90 min
Backup

Electrical

Frequency50/60HZ
Input Voltage120/277VAC

Physical

Battery3.6V 2000mAh Nickel Cadmium
Discharge Time90 minutes minimum
Housing MaterialInjection-molded thermoplastic ABS + polycarbonate cover (UL 94V-0)
IP RatingIp65
MountingWall mount
Operating Temperature0°C to 40°C

Certification

CertificationsUL

Warranty

Lifespan24 hours

📦 Shipping & Dimensions

ModelProduct WeightPackage WeightPackage Dimensions (L×W×H)Units/Carton
6W3 lbs18 lbs18" × 14" × 11"6

Photometric Performance Data

Professional IES-standard luminous flux measurements at 25°C, 4000K Ra70. Data certified for lighting design calculations and municipal specifications.

Photometric data for this product series. Contact sales@auvolar.com for detailed IES files and photometric reports.

Efficacy Comparison

lm/W — higher is better

EX06 Series (this product)
150 lm/W
Industry LED Average
130 lm/W
HPS (High-Pressure Sodium)
110 lm/W
Metal Halide
90 lm/W

* Peak efficacy measured from LM-79 test data. Competitor values are industry typical ranges.

🔆 Run a Free Photometric Simulation

Upload your floor plan and let LightSpec AI calculate foot-candle levels, uniformity ratios, and recommended pole spacing — in under 60 seconds.

Try LightSpec AI →

💡 LED Upgrade ROI Calculator

See the financial case for switching to LED in seconds.

Annual Energy Savings
$3,784
💰
Energy Reduction
54.0%
Payback Period
4.0 yrs
10-Year Net Savings
$22,843
CO₂ Reduction
13.5 tons/yr
DLC Utility Rebate Estimate
$2,000
~$100/fixture avg
Payback timeline4.0 of 10 yrs

* Calculations based on standard operating conditions. Actual savings depend on local utility rates and rebate availability. CO₂ based on EPA eGRID national avg (0.855 lbs/kWh).

Commercial & Municipal Lighting Applications

Professional LED lighting solutions with IES standards compliance for nationwide installations. Request a free LightSpec AI photometric layout or request a project quote.

No accessories available for this product.

Quick Summary

The Auvolar Led Exit Sign Emergency Light EX06 Series operates at 6W, is UL Listed, and offers a 5-Year Limited Warranty with 120/277VAC input.

Frequently Asked Questions

What is the wattage of the Auvolar EX06 Series Exit Sign?
The Auvolar EX06 Series Exit Sign has a wattage range of 6W.
Is the Auvolar EX06 Series Exit Sign UL listed?
Yes, the Auvolar EX06 Series Exit Sign is UL Listed.
What is the lifespan of the Auvolar EX06 Series Exit Sign?
The lifespan of the Auvolar EX06 Series Exit Sign is 24 hours.
What voltage does the Auvolar EX06 Series Exit Sign operate on?
The Auvolar EX06 Series Exit Sign operates on 120/277VAC.
What is the discharge time for the Auvolar EX06 Series battery?
The battery discharge time for the Auvolar EX06 Series is 90 minutes minimum.
